RJ45 Female Jack 8P8C 6 Port Hub to 8 Pin Screw Terminal Block Adapter for Servo Application

Name: RJ45 Female Jack 8P8C 6 Port Hub to 8 Pin Screw Terminal Block Adapter for Servo Application
Brand: Jetacon
Price: 1 USD

RJ45 Female Jack 8P8C 6 Port Hub to 8 Pin Screw Terminal Block Adapter for Servo Application Manufactures

Brand Name : Jetacon

Model Number : RJ45-8P8C-6-Port or 4-Port

Certification : UL, CE

Place of Origin : Guang Dong

MOQ : 10 Pieces

Price : US $16.99

Payment Terms : T/T, L/C, Paypal, Payoneer

Supply Ability : 1KK poles monthly

Delivery Time : 7-20 working days

Packaging Details : Standard Export Carton

Type : RJ45 8P8C

Application : Servo Motion

Gender : Female

Contact Now

Pitch 3.81mm / 0.15" screw terminal block.
Simple DIN Adapters (Feet): for width 35 / 32 / 15mm DIN rails.
Solder connection holes, three (3) per line, supports addition of 0.1" pin headers.
FR-4 fiber glass PCB, dual copper layers.
External dimensions: 89 x 49.5 x 38mm (W x L x H).
Rated voltage: 100V.
Rated current: 0.5A / per pin.
Operating Temperature: -20ºC to 50ºC
Terminal block specifications:
Wire range: 26 ~ 16AWG.

Note: some times the item is from customized products, the actual product will have some minor difference from the photo, thanks.

RJ45 Female Jack 8P8C 6 Port Hub to 8 Pin Screw Terminal Block Adapter for Servo Application

RJ45 Female Jack 8P8C 6 Port Hub to 8 Pin Screw Terminal Block Adapter for Servo Application Images
